CDS Me - Single Person Office Pod

CDS Me - Single Person Office Pod

Regular price $8,000.00 AUD
Regular price $10,670.00 AUD Sale price $8,000.00 AUD
Sale Sold out
Tax included.

This product is assembled and ready to be shipped.

Contact us to see if it will fit into your location.

Special price for the current inventory.

The Serene range is from a vibrant business that is looking to shake up the commercial market, in particular the large North American businesses.

With a strong focus on high end finish, quality and sustainability in mind. We love this range because of their attention to detail and advanced tech options.

The product can reduce sound by up to 35Db which makes a conversation private from those outside the booths. all the range is moveable with inbuilt rollers and if needed it can be disassembled as easily as assembled.

Blue colour in stock & assembled. Other colours can be ordered but will require some time before dispatch.


Features:

Providing a private area for phone calls, our range of acoustic office phone pods is designed with your office in mind. Allowing co-workers to take private phone calls without using up meeting space or having to leave their office.

Technical Specs

Exteriors Size
H2150 x W1000 x D1000mm
Interiors Size
H1992 x W870 x D902mm
Pack Size
H750 x W1150 x D2250mm
Work Bench
H1050 x W700 x D320/200mm
Weight
Net weight: 320kg / Pack weight: 400kg
Power
110-240V; 50/60Hz
Glass Rear
10mm tempered glass/clear
Glass-Door
2.0-5.0 thick aluminium alloy frame+6mm tempered glass/clear, black frame only
Ventilation
Dimmable 1 nos Silent fan, up to 900 RPM, ceiling hidden
Wall Filler
acoustic fiber + gypsum board
Hinges
2 nos, soft closing with 135 degree opening.
Motion Sensor
1x light & fan sensor
Lighting
Dimmable 1x 15W,6000K, 40-800LM
Power Cord
2 Meters
Foot Cap
4x inner levelling feet




Technical Bank instructions for Booth

Power


Power instructions of CDS Booth Product

1: HDMI-Resolution ratio: Support 720P, 1080P
2: Internet Outlet-Model: RJ45 Standard: 23AWG Cat-6
Transmission rate: 1000Mbps
3: Telephone Outlet-Model: RJ 11 CAT3 Plugging times >750times1080P




Furniture Options


    Active furniture in Booth

    ACTIVE
    Inspired by whirlpools, the Active stool is designed for improving posture, balance and stability, while also allow gentle movement to enhance focus and attention for active users. Two buttons available under the seat to adjust the height range more conveniently.


     Balans furniture in Booth

     BALANS

    Balans provides the freedom to your body's micro-adjustments it needs to keep on task, a better way to incorporate your movements in a healthier way, and you will find that you will be more engaged in your work.

    Cloud furniture in Booth

    CLOUD
    Cloud stool is serious designed special for the CDS collections. The well structured powder coat base and foot rest gives the user a solid support and cushion pad seat provides extra comfy makes cloud an ideal seating for your quick meetings, informal talks.



    Colours

    Exterior | Standard

    Colors of CDS Booth
    Exterior | Made-to-order

    Colours selected by order for CDS Booth


    Other Specifications:

    People Comfort: 1
    PRODUCT SIZE External:
     1000x1000x2150mm
    PRODUCT SIZE Internal: 870x902x1992mm

    Chair in the Booth

    Highlights


    Health/Safety
    The overall product has through strict selection of materials, and more than 65% of the materials that care for the earth are made of recyclable materials: in order to ensure the health of the air and light sources in the space, the main body is coated with high-quality steel and fully environmentally friendly resin powder, and the sound-absorbing materials are environmentally friendly PET or Danish rockfon Inorganic sound-absorbing rock wool, the light source adopts high-efficiency led lamps, the fabric uses European imported non-toxic printing and dyeing, which meets the European RoHs standards. The structure is safe, the product has passed the SGs test, and the stable and fast installation is convenient for multiple use in the later stage.

    Soundproof
    The perfect external structure design separates the sound from the space to the utmost extent, and silencing the fresh air channel, and the multiple sound barrier design solves the problem of sound leakage; the overall design is based on NSUL MARSHAII Acoustic acoustic simulation design, 55% equivalent area in the space as a sound absorb, the sound-absorbing material is high-quality PET sound-absorbing panel or Danish rockfon sound-ab- sorbing rock wool, which realizes special processing of broadband response local materials. The technology integrates 40% of the equivalent area of active reflected sound. The successfully constructed an acoustic model of sound absorption, sound insulation and vibration reduction.

    Function/Customization
    The multiple flexible application scenarios of the space box in the office space change the way of working, solve various different work forms, and provide a healthy and flexible independent space; but the space box is also widely used in other public spaces, and can be customized Applications that need to address different needs such as privacy, independence, sound insulation, and security. Such as live broadcast space, learning space, sleeping space, leisure water bar space, dressing space, and more professional medical services. And can use technology and SG technology system to achieve linkage management and remote charging functions.

    Sustainability

    More than 85% of materials can be recycled
    layers of glass door surface plate

    Reinforced glass, door/Surface plate
    Door and Surface plate board system use one side high grade reinforced glass, it has good function for permeability, and material has high fights impulse strength tall, cause harm not easily to human body, have good thermal stability more. make the application more flexible.

    Felt out of recycled Pet bottles feature for booth
    PET
    Instead of creating more plastic that could wind up in nature or the landfill, we made our felt out of recycled PET bottles. Acoustic Felt - recycled PET is a next generation textile made from certified recycled PET bottles sourced from recycling entities.

    Cloth Board feature in CDS Booth
    Cloth board
    (with steel plate sound-absorbing rock wool)
    The surface is made of polyester fabric, which has high strength and elastic recovery ability. and is the most durable and heat-resistant fabric.Cloth surface can absorb sound effectively, the colour has very good decorate effect. Using PET sound-absorbing board has a sound absorption coefficient of0.9 or more in the noise range of 125-4000Hz, which shortens the adjustment reverberation time, removes sound impurities, and improves the clarity of speech. It also has good fire resistance, and its formalde- hyde test result is 0.05/1, which meets the requirements of national standards. The product has the characteristics of heat preservation, flame retardant, light weight, stability, impact resistance.


    Colorful steel plate feature in CDS Booth
    Steel plate
    The steel plate is made of high quality steel with smoothness surface, and stable physical properties.

    Carpet flooring floor feature in CDS Booth
    Carpet/glue flooring floor
    The floor use finished carpets and meets the requirements of fireproof level. Carpet is soft, comfortable and safe, its can reduce noise effectively, heat insulation and decorate the space. The floor of the coffee house is made of finished PVC rubber, which is a good environmental protection material with soft texture, strong abrasion resistance, and effective waterproof and fireproof.
