Collaborative Design Space

Bliss SILENCE - Office Pod - S

Bliss SILENCE - Office Pod - S

In 2019 we decided to provide affordable and funcional booths to service the mid market. Offering a small range of options has helped us keep our costs low and focus our factory on a quality finish that delivers users with 30dB noise reduction and privacy. We are also able to supply a small range of furniture options with each booth to make them how you want.

Features:

Focus Chat is ideal for those calls or conferences where you want privacy and comfort. Sound reduction of upto 30db provides that privacy. With power from 240v to 12v combined with LED lighting and ventilation makes the Chat great a buy. Manufactured with high strength materials and 5mm laminated double glass with sealed safety locking door. Standard external colours Matt Black and White, with a range of acoustic panelling options. Use laptops, tablets and smart phones with power and connectivity assured.

Specifications:

1. Frame structure:
The frame profile of the cabin wall structure is 6063-T5 reinforced aluminum alloy profile, which is anodized and corrosion-resistant. The surface can be multi-color matte sprayed, and the standard colors are black and white. The ceiling material of the cabin is an aluminum alloy inner frame structure, the panel is a sound-absorbing board plus a splint, sound-proof cotton and gypsum board, and the top layer is self-adhesive sound-absorbing cotton.
Mechanical properties:
Tensile strength σb (MPa): ≥205 Elongation stress σp0.2 (MPa): ≥170
Elongation δ5 (%): ≥7

2. Panel material:
Double-layer 5mm thick tempered ultra-white damping laminated glass, which has the characteristics of safety, high strength, bending resistance, thermal stability and sound insulation.
The acoustic structure of the cabin wall panel is double environmental protection board covered with 1.0mm thick steel plate (matte spraying treatment on the surface), and the acoustic cavity layer is specially treated; the interior surface of the space is made of porous environmental protection acoustic cotton board, combined with the unique non-closed bubble type The pore structure forms broadband absorption to ensure the comfort of the inner space.
Including glass door hardware accessories (2 pieces of 304 stainless steel, 1 glass door lock, 4 strong support wheels reserved for the cabin base).

3. Equipment configuration:
Silent air supply and exhaust system (1 set of intake fan + 1 set of exhaust fan), 1 LED energy-saving lamp, 1 set of sensor switch and adapter power base (100-240V and 12V-USB) insulation.

Price not including furniture.

Other Specifications:

People Comfort: 1
PRODUCT SIZE External:
 950x950x2200mm
PRODUCT SIZE Internal: 820x820x2070mm
